‘EcoSeeder’ Seed Drill Seeder Mechanism
Pt. No. 67392
Issue 0918
ITEM PART No. DESCRIPTION SINGLE DUAL
14R 16R 18R 16R 18R
1 43375 Metering Housing 14 16 18 32 36
2 43376 Shutter Slide 14 16 18 32 36
3 43377 Seed Metering Wheel (includes item 4) 14 16 18 32 36
4 43374 Fine Seed Wheel (for spares ordering only)
5 43378 Bottom Flap & Bolt Assembly 14 16 18 32 36
6 22550 Seeder Extension Funnel 14 16 18 32 36
7 22551 Seed Diverter 14 16 18 32 36
8 22548 Spring Clip S/S 14 16 18 32 36
9 43379 Seed Shaft Guide Bearing 2 2 2 4 4
10 43380 Guide Bearing Tension Spring 2 2 2 4 4
11 43382 Metering Wheel Clutch Hook 1 1 1 1 1
12 43383 Seed Rate Disc Calculator 1 1 1 1 1
13 43362 Fine Seed Wheel Brush (Optional Extra)
