Duncan EcoSeeder - EcoSeeder Seed Drill Agitator Shaft Assembly

65
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Single Seedbox Assembly
ITEM PART No. DESCRIPTION QTY
1 61184 Single Box Assembly 14 Run (with seeder hardware) 1
1 61186 Single Box Assembly 16 Run (with seeder hardware) 1
1 61188 Single Box Assembly 18 Run (with seeder hardware) 1
2 61190 Single Box With Lid 14 Run (painted sheetmetal - no hardware) 1
2 61191 Single Box With Lid 16 Run (painted sheetmetal - no hardware) 1
2 61192 Single Box With Lid 18 Run (painted sheetmetal - no hardware) 1
3 61210 Lid Only 14 Run 1
3 27930 Lid Only 16 & 18 Run 1
4 26599 Calibration Tray Bracket (not shown) 2
5 27919 Box Set Mounting Bracket 2
6 Refer Page 66 Agitator Drive Assembly 16 & 18 Run (Not 14 Run) 1
7 Refer Page 59 Seeder Assembly
14 16
18
8 10158 Box Quadrant Plate Reversed 1
9 22419 Box Shaft Connecting Sleeve 2
10 61214 Box Shaft (20mm) 14 Run 1
10 27914 Box Shaft (20mm) 16 & 18 Run 1
11 61215 Flap Shaft (18mm) 14 Run 1
11 27915 Flap Shaft (18mm) 16 & 18 Run 1
12 60098 Rear Flapshaft Handle w/assy 1
13 22568 Location Tab (Calibration Tray) 2
14 61241 Transfer Ecoseeder 14Run 2
14 27942 Transfer Ecoseeder 16 & 18 Run 2
15 29163 Hinge Assembly 3
16 22491 Hinge Pin 3
17 27599 Hinge Pin Spring Clip 3
18 43373 Black Edge Trim (2.0m 14 Run 2.3m 16 & 18 Run) 1
19 45019S M12 x 30 Class 8.8 Set Screw Z/P 6 8 8
20 45159SS M12 HD Flat Washer S/Steel 6 8 8
21 45139 M12 Nyloc Nut Z/P 6 8 8
22 45186 M10 x 12 Socket Head Grubscrew 2
23 45758 M6 x 16 Countersunk Posidrive Screw Z/P 2
24 45909 M6 x 20 Pan Head Machine Screw Z/P 10
25 45907 M6 x 12 Pan Head Machine Screw Z/P 4
26 45122 M6 Hex Nut Z/P 2
27 45136 M6 Nyloc Nut Z/P 14
28 45150 M6 Light Flat Washer Z/P 6
29 45158 M10 HD Flat Washer Z/P 1
30 45368 M10 Starlock Fixing Washer 2
31 22487 Latch Rod Assembly 1
