71
Pt. No. 67392
Issue 0918
‘EcoSeeder’ Seed Drill Disc Opener Assy (Option)
ITEM PART No. DESCRIPTION QTY
1 E214WDO Disc Opener Complete 14 Run 1
1 E216WDO Disc Opener Complete 16 Run 1
1 E218WDO Disc Opener Complete 18 Run 1
2 61234 Disc Opener Frame 14 Run 1
2 61232 Disc Opener Frame 16 Run 1
2 61230 Disc Opener Frame 18 Run 1
3 25562 Disc Opener Frame Support 2
4 43053 Top Link 20.5 x 28.5 x 3/4 Dia (Not Shown) 1
5 43352 Seal 14 16 18
6 17537 Bearing Housing 14 16 18
7 18364 Bearing Housing 14 16 18
8 11351 Bearing 28 32 36
9 11353 Plain Disc 12-1/2" Dia. 14 16 18
10 21268 T Bolt Assembly 7 8 9
11 21265 Disc Opener Spring 7 8 9
12 21279 Double Pivot Pin Assembly 7 8 9
13 21245 Attatchment Arm Pivot 2
14 21690 Clamp Plate 9 10 11
15 60460 Disc Mounting Bracket 7 8 9
16 27606 Double Axle Arm Assembly 7 8 9
17 22080 Dust Cap 14 16 18
18 11361 Hub Cap 14 16 18
19 22078 Seal Collar 28 32 36
20 47461 1" Light Flat Washer Z/P 14 16 18
21 45051 M16 x 130 Class 8.8 Bolt Z/P 18 20 22
22 45140 M16 Nyloc Nut Z/P 18 20 22
23 45141 M20 Nyloc Nut Z/P 21 24 27
24 45001S M10 x 20 Class 8.8 Set Screw Z/P 86 98 110
25 45003 M10 x 30 Class 8.8 Set Screw Z/P 7 8 9
26 45166 M10 Spring Washer Z/P 2
27 45138 M10 Nyloc Nut Z/P 91 103 115
28 43118 Grease Nipple Straight 9 10 11
29 47154 3/4" UNF x 4-1/2" HT Bolt Z/P (Not Shown for Top Link) 1
30 47155 3/4" UNF x 5" HT Bolt Z/P (Not Shown for Top Link) 1
31 47546 3/4" UNF Nyloc Nut Z/P (Not Shown for Top Link) 2
To Next Page
