73
Pt. No. 67392
Issue 0918
ITEM PART No. DESCRIPTION QTY
1 27960 Drawbar Assembly 1
2 43977 2.5 x 8 x 1.5 Hydraulic Ram 2
3 27970 Hydraulic Hose 1.32m Long 2
4 27971 Hydraulic Hose 2.52m Long 1
5 43338 3/8" BSPTM 3/8" BSPF Swivel 90° Elbow 2
6 61258 Hydraulic Block Assembly 1
7 43147 1/2" Male Probe QR Coupling 1
8 43617 1/2" Dust Cover 1
9 43152 3/4" UN 'O' to 3/8" BSP Silencer 2
10 43391 3/8" Dowty Washer 2
11 43392 3/8" BSP MM Nipple 1
12 43393 Ball Valve 1
13 43445 1/2" BSPT to 3/8" BSPP Nipple 1
14 43499 Whoa Stop Collar Set (Not Shown) 2
15 43333 Plastic Tie Strap (Not Shown) 7
16 47251 1" UNF x 3-1/2" HT Bolt Z/P 1
17 47254 1" UNF x 5" HT Bolt Z/P 1
18 47552 1" UNF Nyloc Nut Z/P 2
19 43280 3/4" UN 'O' to 3/8" BSP Nipple 5
‘EcoSeeder’ Seed Drill 3PTL to Trailing conversion
