Dungs MPA 41 PF Series User Manual

55 … 96
54 … 96
Printed in Germany • Edition 04.18 • Nr. 271 958
Display
number
Parameter Value
range
Unit
0 P30 - Duration pre-venting 0...99 1 s
1 P31 - Pre-ignition time 0...99 1 s
2 P32 - First safety time 1...15 1 s
3 P12 - Restart attempts 1...5
4 P34 - Stabilisation time A 0...99 1 s
5 P83 - Duration of the switch-on delay after power on 0...99 1 s
6 P41 - Operation safety time FLW1 08...35 (=0.75...3.5 s) 0.1 s
*1
7 P85 - Pre-venting time HT 0...99 1 s
8 P51 - Post-venting time ame 0...99 1 s
9 P14 - Restart attempts after a ameout 0...5
A P13 - Restart attempts after a missing ame 0...5
b P15 - Fault switch-o in case of opening the safety chain 0= O / 1 = On
C P16 - LDW: Operating mode 0...99
d P18 - Operating mode X17 0...3
E P87 - Jump duration from ame or power On to HT 1...99 1 s
h P17 - Temperature controller: Operating mode 0...4
L P19 - Operating mode output operation 0...99
o P52 - O-period before restart ame 1...99 1 s
n
*2
P11 - Fieldbus address 0...99
*2
*1
Adjustable in increments:
08 = 0.75 s 12/16 (only possible for FLW1, smallest possible adjustment)
oP = 0.8125 s 13/16
09 = 0.875 s 14/16 (for UV41 with 0.125 s reaction time)
10 = 1 s 16/16
15 = 1.5 s 24/16
18 = 1.8125 s 29/16
19 = 1.875 s 30/16 (for UV41 with 0.125 s reaction time)
20 = 2 s 32/16
25 = 2.5 s 40/16
28 = 2.8125 s 45/16
29 = 2.875 s 46/16 (for UV41 with 0.125 s reaction time)
30 = 3 s 48/16
35 = 3.5 s 56/16
*2
Use the shortcut - and + to switch between OFF (display = oF) and the address. Addresses over 99 must be set by means
of VisionBox. Do not use address "0".
Parameterisation display
Parameterisation display
▶
After activating the automatic parameter setting, 19 parameter values must be dened; see parameter
list.
▶ This parameterisation is quit after 30 min. due to a timeout.
▶ A password is required for changing the parameters.
▶
Attention: Some parameter values are displayed in another resolution than in the parameterisation
mode using VisionBox. If it is not possible to display the parameter value in the resolution, -- is dis-
played; nevertheless, the value may be changed in the resolution that can be displayed.
▶
To change service or OEM parameters, the required password or a higher-level password must be
entered (e.g. all service parameters may also be changed using the OEM password).
