Printed in Germany • Edition 04.18 • Nr. 271 958
Bit Register address 26 Description During
Fault
0-7 Resettable start counter
for ame operation
Byte 2 of the 32-bit start counter X
8-15 Resettable start counter
for ame operation
High byte (byte 3) of the 32-bit start counter X
Bit Register address 27 Description During
Fault
0-15 Maintenance counter V1 16-bit maintenance counter, resolution 1000 switching cycles X
Bit Register address 28 Description During
Fault
0-15 Maintenance counter air valve 16-bit maintenance counter, resolution 1000 switching cycles X
Bit Register address 29 Description During
Fault
0-15 Maintenance counter
Watchdog relay
16-bit maintenance counter, resolution 1000 switching cycles X
Bit Register address 30 Description During
Fault
0-15 not used
Bit Register address 31 Description During
Fault
0-7
Additional error information
1. Detailed information on the error message X
8-15 Not used Not used
Bit Register address 32 Description During
Fault
0-7 Article number SW P1 Byte 0 (low byte) of the 24-bit article number X
8-15 Article number SW P1 Byte 1 of the 24-bit article number X
Bit Register address 33 Description During
Fault
0-7 Article number SW P1 Byte 0 (high byte) of the 24-bit article number X
8-15 Index article number SW P1 e.g. 0x5F="_"; 0x41="A", 0x42="B" … X
Bit Register address 34 Description During
Fault
0-7 Day of production of MPA41xxPF X
8-15 Month of production of MPA41xxPF X
Bit Register address 35 Description During
Fault
0-7 Year of production of MPA41xxPF X
8-15 Not used
Bit Register address 36 Description During
Fault
0-7 Device number Byte 0 (low byte) of the 32-bit device number X
8-15 Device number Byte 1 of the 32-bit device number X
Bit Register address 37 Description During
Fault
0-7 Device number Byte 2 of the 32-bit device number X
8-15 Device number Byte 3 (high byte) of the 32-bit device number X
