Page #83 background imageLoading...
Page #83 background image
83 … 96
82 … 96
Printed in Germany • Edition 04.18 • Nr. 271 958
Bit Register address 38 Description During
Fault
0-7 Article number HW Byte 0 (low byte) of the 24-bit article number X
8-15 Article number HW Byte 1 of the 24-bit article number X
Bit Register address 39 Description During
Fault
0-7 Article number HW Byte 2 (high byte) of the 24-bit article number X
8-15 Index article number HW e.g. 0x5F="_"; 0x41="A", 0x42="B" ... X
Bit Register address 40 Description During
Fault
0-7 Article number device Byte 0 (low byte) of the 24-bit article number X
8-15 Article number device Byte 1 of the 24-bit article number X
Bit Register address 41 Description During
Fault
0-7 Article number device Byte 2 (high byte) of the 24-bit article number X
8-15 Index article number device e.g. 0x5F="_"; 0x41="A", 0x42="B" … X
Bit Register address 42 Description During
Fault
0-7 Article number SW EM Byte 0 (low byte) of the 24-bit article number X
8-15 Article number SW EM Byte 1 of the 24-bit article number X
Bit Register address 43 Description During
Fault
0-7 Article number SW EM Byte 2 (high byte) of the 24-bit article number X
8-15 Article number SW EM e.g. 0x5F="_"; 0x41="A", 0x42="B" … X
Bit Register address 44 Description During
Fault
0-7 Day of production of EM 2/4 X
8-15 Month of production of EM 2/4 X
Bit Register address 45 Description During
Fault
0-7 Year of production EM of EM 2/4 X
8-15 Not used
Bit Register address 46 Description During
Fault
0-7 Device number EM Byte 0 (low byte) of the 32-bit device number X
8-15 Device number EM Byte 1 of the 32-bit device number X
Bit Register address 47 Description During
Fault
0-7 Device number EM Byte 2 of the 32-bit device number X
8-15 Device number EM Byte 3 (high byte) of the 32-bit device number X
Bit Register address 48 Description During
Fault
0-7 Article number HW-EM Byte 0 (low byte) of the 24-bit article number X
8-15 Article number HW-EM Byte 1 of the 24-bit article number X
