3.
Extract the nozzles from their side housings;
4.
Clean the holes of the nozzles with a pin (3);
5.
Keep the recovery tank trimmers clean at all
times.
Figure 3 1.23
GENERAL MAINTENANCE
The mechanical parts of the DUPLEX machine do not require periodic maintenance by the
operator as their gears all run on bearings.
1.17 PRECAUTIONS FOR USE OF THE STEAM GENERATOR
1.
Never leave the steam generator turned on or in operation if there is no water in the tank;
2.
After each use, turn off the main switch on the boiler;
3.
Clean the outside of the steam generator with a damp cloth;
4.
Do not wash the generator under running water;
5.
Clean the spray nozzles with a damp cloth and dry with a brush;
6.
Clean the holes with a paper clip;
7.
Keep the water tank clean;
8.
Replace the sand filter at least once a year.
WARNING
Do NOT touch the steam spray nozzles or the metal panels of the machine
with your hands due to the high temperatures that they reach during
operation.
