This ends the installation procedure.
2. INSTALLING PROCEDURE
Fix the communication cable to connecting
plate of LU-HM.
<< Parts to be used >>
Cable clamp r ................................................... 2
Screw (MSKW4 × 8) t ..................................... 2
3
Cable clamps
Connecting plate
Suction collator
NOTE : Move the DBM-120 unit to and fro when changing the paper size. Move aside the power cord so that it does
not touch the DBM-120 at this time.
