Do not leave this Installation Manual at the installation site after installation.
Furthermore, do not leave tools used for the installation, at the installation site.
Retain this Installation Manual for future reference as it will be needed for subsequent
maintenance such as relocation.
TO SERVICING PERSONNEL
TABLE OF CONTENTS
1. Standard Accessories ..................................... 1
2. Installing Procedure ........................................ 2
2-1. Releasing the DBM-120 Lock .................. 2
2-2. Checking the DBM-120 EPROM .............2
2-3. Setting the DBM-120 ............................... 4
2-4. Checking the Suction Collator EPROM ...6
2-5. Setting the DIP Switch of Suction
Collator .................................................... 7
2-6. Connecting the Suction Collator ..............7
2-7. Connecting the Communication Cable ....9
To Next Page
