MAJOR COMPONENTS AND ASSEMBLIES
1 Control Panel 8 Feed Rollers
2 Top Cover 9 Feed Tray Tension Adjustment Lever
3
Catcher – Set Up for Business Card
10
Side Guide
4 Waste Bin 11 Feed Tray
5 Slitting Alignment Knob 12 Die Module Skew Correction Thumb Nut
6 Cutting Knife 13 Slitter Module
7 Die Module 14 Catcher – Set Up for Greeting Card
4
5
3
6
7
8
9
11
12
10
13
14
