Duplo DocuCutter CC-330 Service And Parts Manual

11
. Cutting Knife Asm 882-105-000A
Index P/N Part Name Qty Remarks
1.05.01 882-105-010A Knife, Upper, CC-330 1
1.05.02 882-105-020A Knife, Lower, CC-330 1
1.05.03 882-105-030A Bar, Knife Asm Mounting, CC-330 1
1.05.04 881-713-0000 Bracket, L, Upper Knife Mounting, CC-228 1
1.05.05 881-714-0000 Bracket, R, Upper Knife Mounting, CC-228 1
1.05.06 881-714-0000
Asm, Spring, Middle, Knife Holding
, CC
-
228
2
1.05.07 881-715-0000
Asm, Spring, Left, Knife Holding
, CC
-
228
1
1.05.08 881-716-0000
Asm, Spring, Right, Knife Holding
, CC
-
228
1
1.05.09 881-717-0000
Nut,
Middle,
Knife Holding
Spring
,
CC
-
228
2
1.05.10 881-718-0000 Nut, L/R, Knife Holding Spring, CC-228 2
1.05.11 882-105-110A
Block, R, Lower Knife Mounting, CC
-
330
1
1.05.12 882-105-120A
Block, L, Lower Knife Mounting
, CC
-
330
1
1.05.13 882-105-130A Chassis, Sensor Mounting, CC-330 1
1.05.14 881-719-0000 Link, Cutting Knife, Driving, CC-228 2
1.05.15 882-105-150A Shaft, Cutting Knife Driving, CC-330 1
1.05.16 882-105-160A Arm, R, Cutting Knife Driving, CC-330 1
1.05.17 881-720-0000 Arm, L, Cutting Knife Driving, CC-228 1
1.05.18 882-105-180A Block, Cutting Knife Driving, CC-330 1
1.05.19 881-722-0000
Shutter, Cutting Knife
Interrupter
, CC
-
228
1
1.05.20 00B-000-0696 Ball Bearing, 696ZZ 2
1.05.21 00B-000-1260 Ball bearing, 1260ZZ 1
1.05.22 00B-00F-6900 Ball Bearing, F6900ZZ 1
1.05.23 00B-000-6900 Ball Bearing, 6900ZZ 1
1.05.24 882-105-240A Bushing 2
