. PARTS ON NON OPERATING SIDE

Index P/N Part Name Qty Remarks

1.4.01 00B-000-0451 Belt, 171mxl, 10mm 1

1.4.02 882-140-200A Roller, Idler, CC-330 1

1.4.03 00M-000-0403 Motor, SQ, 75mm, 3A, 2.58V 1

1.4.04 00M-000-0403 Motor, SQ, 75mm, 3A, 2.58V 1

1.4.05 882-140-050A Block, Cutting Knife Driving, CC-330 1

1.4.06 881-403-0000 Spring, Feed Tray Tension, CC-228 1

882-140-060A Spring, Feed Tray Tension, CC-330 1

1.4.07 00A-000-1211 Asm, PCB, Power 1

1.4.08 882-140-080A Arm, Cutting Knife Main Driving, CC-330 1

1.4.09 882-140.090A Link, Cutting Knife Driving 1

1.4.10 00M-000-0403 Motor, SQ, 75mm, 3A, 2.58V 1

1.4.11 00B-MXL-171D Belt, 171 MXL, 10mm 1

1.4.12 08P-51G-0800 Pulley, 0.08P, 51G, 8MM 1
