Duplo DocuCutter CC-330 Service And Parts Manual

13
. Slitting Module, 2” x 3.5” 882-112-010A
Index P/N Part Name Qty Remarks
1.06.01 882-106-010A Frame, Slitter, 2x3.5”, CC-330 1
1.06.02 882-106-020A Cover, Upper, Slitter, CC-330 1
1.06.03 882-106-030A Cover, Lower, Slitter, CC-330 1
1.06.04 882-106-040A Cover, Top, Slitter, CC-330 1
1.06.05 00H-000-0015 Handle, Slitter, CC-228 2
1.06.06 882-106-060A Shaft, Slitter, CC-330 2
1.06.07 882-106-070A Block, Anti Shaft Bending, CC-330 1
1.06.08 882-106-080A Base, Slitting Wheel, Upper, Center, CC-330 2
1.06.09 882-106-090A Base, Slitting Wheel, Upper, Side, CC-330 2
1.06.10 882-106-100A Collar, Slitting Wheel Holding , CC-330
6
1.06.11 882-106-110A Slitting Wheel, Upper, CC-330 6
1.06.12
00B-000-6802
Ball Bearing, 6802ZZ 1
1.06.13 882-106-130A
Spring
, Compression, Wheel Tension, CC-330
36
1.06.14 882-106-140A Base, Slitting Wheel, Lower, Center, CC-330 2
1.06.15 882-106-150A Base, Slitting Wheel, Lower, Side, CC-330 2
1.06.16 882-106-160A Collar, Lower , Center Slitter, CC-330 2
1.06.17 882-106-170A Collar, Lower, Side Slitter, CC-330 2
1.06.18 882-106-180A Slitting Wheel, Lower, CC-330 4
1.06.19 882-106-190A Gear, CC-330 2
1.06.20 00B-000-6902 Ball Bering, 6902ZZ 4
1.06.21 882-106-210A Guide, Waste, Center Gutter, CC-330 2
1.06.22 882-106-220A Guide, Waste, Side Trim, CC-330 2
1.06.23 882-106-230A
Plate,
Screw, Waste Guide Fastening, CC-330
4
