3-2 Cutting Tools Installation
Select the type of tool you need.
Tool Name J201 J202 J205 J206 J208
Paper Type Paper/Card Paper/Card Card Stickers Sticker
Paper Thickness
(gsm)
120-300gsm 150-400gsm 400-1kg Sticker or less
than 300gsm
Blade Installation Procedures
a. Unscrew the cap of the blade holder:
b. Put a blade into the holder and push it to the end:
c. Put the cap back and leave about 2mm of the tip of the blade out of the cap. Make
sure the tip can rotate freely in the holder:
d. Put the holder to the cutting head of the cutter. Make sure the holder is put in
posi4tion. Fasten the holder by a flat screwdriver
