Troubleshooting
Master
Lever
Master clamp
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Lift the lever toward you.
The master clamp opens and the edge of the master will be
released from the clamp. If the master is stuck, release it
manually.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Return the lever.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Pull the front end of the master toward you and
press the JOG switch intermittently.
Hold the switch down until the master peels off.
IMPORTANT
• Discard the old master, making sure that it
does not touch your clothing.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Hold the JOG switch down until the drum comes to a stop with a beep.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Close the master ejection box, pressing it until it
locks.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
When “MASTER EJECT MISS” is Displayed
JOG switch
Continue Page
•••
To Next Page
