Troubleshooting
The message “MASTER SET MISS” is displayed on the LCD panel. Remove the master and remake the plate by
following the procedure below.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Open the upper cover.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Remove the master left in the master feeder.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Gently close the upper cover.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
When “PLATE EJECTION ERROR” is Displayed
When “MASTER SET MISS” is Displayed
MASTER SET MISS
Upper cover
Continue Page •••
