DUROMAX MX4500E - Page 35

32
2 FRM2 FRONT PROTECTING PLATE PCS
2
3 FRM3
RUBBER BOTTOM / INCLUDE LEFT
ONE AND RIGHT ONE
PCS
2
4 FRM4 NUT / GB6177-M8 PCS
8
5 FRM5
RUBBER BOTTOM / INCLUDE LEFT
ONE AND RIGHT ONE
PCS
2
6 FRM6 SIDE PROTECTING PLATE PCS
2
Series
No.
Part Code English Name
Unit
Quantity
for One
Unit
1 OTLTR1
REAR-END COVER OF
ALTERNATOR
PCS
1
2 OTLTR2 BOLT / GB5789-M5*12 PCS
2
3 OTLTR3
REGULATOR ASSY AUTOMATIC
VOLTAGE
PCS
1
4 OTLTR4 BOLT / GB5789-M6*130 PCS
4
5 OTLTR5
REAR-END SUPPORTER OF
ALTERNATOR
PCS
1
6 OTLTR6 BOLT / GB5782-M8*180*1 PCS
1
7 OTLTR7 ROTOR COMP PCS
1
8 OTLTR8 STATOR ASSY PCS
1
9 OTLTR9 BRUSH ASSY PCS
1
10 OTLTR10 BOLT / GB5789-M5*12 PCS
2
11 OTLTR11 BOLT / GB5789-M5*12 PCS
1
12 OTLTR12 HOLD DOWN PLATE PCS
1
13 OTLTR13 BOLT / GB5787-M6*12 PCS
1
14 OTLTR14 RED GASKET /Φ6.2*Φ10*0.8 PCS
2
