DUROMAX XP20HP - Engine Components

1. Air Filter - A removable, cleanable, oiled, element that cleans the air going into the engine.
2. Carburetor - A component used to control the air fuel mixture of the engine.
3. Fuel Tank - All metal 1.79 gallon gasoline fuel tank.
4. Recoil Starter - An easy pull recoil start to start the engine without the electric start.
5. Recoil Handle - An easy grip handle used to pull the recoil starter rope.
6. Muer - A noise dampening component that helps lower the engine decibel level.
7. Engine Shaft - A 1” diameter, 3.535” long all metal shaft with a 1/4” keyway.
8. Oil Fill - An easy access location to ll the oil for the engine.
9. Oil Drain Plug - An easy to remove oil plug that is used to drain the oil.
ENGINE COMPONENTS
13
3. Fuel Tank
6. Muer
7. Engine Shaft
8. Oil Fill
4. Recoil Starter
2. Carburetor
1. Air Filter
9. Oil Drain Plug
5. Recoil Handle
