Displacement 500cc
Fuel Type ≥87 octane, ≤10% ethanol, unleaded gasoline
Dry Weight 77 lbs
Maximum Torque 22.87 ft. lb @ 2500 rpm
Compression Ratio 8.5:1
Bore X Stroke 94 mm x 72 mm
Engine Oil Capacity 40.5 oz. (1.2 L)
Fuel Tank Capacity 1.79 gal. (6.78 L)
Lowest Idling Speed 2100 rpm ± 200 rpm
Dimensions LENGTH 19 in.
WIDTH 17 in.
HEIGHT 19 in.
Engine Type 4-Stroke OHV Forced-Air
Ignition System Non-contact transistor
Lubrication Mode Splash
Starting Type Recoil
Shaft Rotation Counter-clockwise
Shaft Size 1” diameter, 3.535” long, 1/4” keyway
Shaft End 3/8” size 24 UNF - 2B drilled and tapped
Center of Shaft to Base 5.26”
Bearing Type Stainless steel ball bearing
Cylinder Sleeve Type Cast iron sleeve
Fuel Delivery System Carburetor
SPECIFICATIONS
43
