25
Install wheels
a. Place the wheels onto either side of the axle.
5.
Install cotter pins
a. Place a cotter pin through the hole in each end of
the axle and bend it out to secure the wheels.
7.
Install outside wheel washers
a. Place the other large washers onto each side the
axle in front of the wheel.
6.
Install handles
a. Attach the handles to the brackets on the frame
using the provided bolts and nuts.
b. Flip the assembled generator over onto its wheels
and support brackets.
Do not over tighten the handles, it will prevent
free movement.
8.
