DV Systems IS Series User Manual

SDI-01
Feb ‘15
- 12
-
Compressor Unit Parts
Compressor Assembly Parts.
Noted below and on the following page are listings of the major components used in the Compressor Assemblies.
Please pay close attention to the model numbers of the Units to ensure that you choose the correct components.
1 to 3 HP Compressor Units.
Description: SDI1-2030 SDI2-3030 SDI3-3060 SDI3-4060
Pump Assembly DEV-20 DEV-30 DEV-30-1 DEV-40
Intake Filter Assembly PB-21175002 PB-21175002 PB-21175002 PB-21175002
Intake Filter Element PB-21177012 PB-21177012 PB-21177012 PB-21177012
Beltguard Assembly EG-9489 EG-9489 EG-9489 EG-9493
Motor Pulley – 1 Phase PU-9243 PU-9244 PU-9267 PU-9248
Motor Pulley – 3 Phase PU-9244 PU-9244 PU-9248
Belt BT-67 BT-9039 BT-9047 BT-9045
Tank TA-9504 TA-9504 TA-9505 TA-9510
Pressure Switch SSS-9002-U80100 SSS-9002-U80100 SSS-9004-U110135 SSS-9002-U80100
Pressure Gauge GA-250 GA-250 GA-250 GA-250
Tank Safety Valve TIA-5140 TIA-5140 TIA-5150 TIA-5140
Tank Drain Ball Valve VA-9411 VA-9411 VA-9411 VA-9411
Tank Ball Valve VA-9411 VA-9411 VA-9705 VA-9705
Check Valve CCV-9401 CCV-9401 CCV-9401 CCV-9401
Maintenance Kits:
The appropriate Maintenance Kit for the 1 to 3 HP Units noted above having the ‘DEV-20’, ‘DEV-30’, DEV-30-1’
and ‘DEV-40’ Pumps is:
MK-40 Maintenance Kit
Each kit consists of:
(3) PB-21177012 Intake Filter Element
(1) PR-31-4 30 Weight Mineral Oil – 1 litre
