DV Systems IS Series User Manual

SDI-01
Feb ‘15
- 2 -
18”
18”
24”
18”
Behind
Quick Start
Mechanical Installation.
(Refer to Page 7)
Lubrication.
(Refer to Page 8)
 The Unit should be located in a dry, clean,
cool, dust free, and well ventilated area.
 Allow a minimum 18” behind the BeltGuard and
around the Unit.
 The ambient temperature should be between
10°C and 40°C (50°F and 104°F).
 Ensure that the floor under the Unit is smooth,
level and capable of bearing the weight of the
Compressor.
 If installed in a compressor room, ensure that
the room is adequately ventilated
The arrow at right
indicates the
correct rotation of
the Flywheel.
Pump Rotation.
(Refer to Page 10)
Proper Oil
Level
Note:
The Unit is shipped with ‘PR31’ 30
Weight Compressor Oil in the Pump.
Verify the proper level as indicated
above before starting.
