DVS DS100S Series - Specifications; DS100 S-40 and DS100 S-75 Parameters; Operating Environment

DS100S AC Servo Manual
Specifications
Operating Environment
Cooling
Natural Cooling or Forced Cooling
Operating
Environment
Environment
Avoid dust, oil fog and corrosive gases
Ambient Temp
0~+40
℃
Humidity
40%RH to 90%RH, no condensation
Vibration
5.9m/s
2
MAX
Storage Temperature
-20℃ to 80℃
Parameters
DS100S-40
DS100S-75
Output Power
50W-400W
400W-1000W
Main Supply
1 phase/3 phase
AC220V-240V
50/60Hz
Power Supply for
Control Circuit
1 phase 220VAC
Control Method
0: position control
1: velocity control
2: test trial control
3: JOG control
4: torque control
Protect Function
over speed/under voltage/over voltage/over current/over load/encoder
error/control supply error/position error
Monitoring Function
velocity/current position/command pulse accumulation/position
error/motor torque/motor current/working state
Control Input
1.servo enable 2.alarm clearance 3.CCW driving ban 4.CW driving ban
5.deviation counter clear zero 6.command pulse ban 7.CCW torque
limitation 8. CW torque limitation
Control Output
servo ready/servo alarm/GPS test/mechanical brake
Resistance Braking
Built-in/Built-out
Suitable Load
Less than 5 times of the motor inertia
Display
5 LEDs , 4 keys
Command Input
1: pulse+direction
2: CCW/CW
3: A phase/B phase
Electronic Gear Ratio
1/32767-32767
