Dymo LabelWriter 4XL Quick Start Guide

4
3. Connecting your LabelWriter Printer
NOTE Do not connect the printer to your computer until after the
software installation is complete.
To connect the power
1 Plug the power cord into the power adapter. See Figure 3.
2 Plug the power adapter into the power connector on the bottom of
the printer. See Figure 4.
3 Plug the other end of the power cord into a power outlet.
4 Plug the USB cable into the USB port on the bottom of
the printer.
5 Insert the power and USB cables through the cable channel
and set the printer down.
6 When the software is completely installed, connect the
other end of the USB cable into an available USB port on
your computer.
Mac OS If the printer is not in the printer list when the installation is complete, refer to the
ReadMe file for instructions on how to add the printer.
Figure 3
Power adapter
Power cord
USB
24VDC
Figure 4
PowerUSB
Cable
channel

Dymo LabelWriter 4XL Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	106 mm
Mac compatibility	Yes
Compatible operating systems	Windows XP, Vista, 7 Mac OS v.10.4 +
Product color	Black, Silver
Customs code	8443321000
Country of origin	China
Dimensions (WxDxH)	178 x 187 x 134 mm
Quantity outer carton	2 pc(s)
Net weight of outer carton	4.400 kg
Gross weight of outer carton	4.850 kg
Wi-Fi	-
Standard interfaces	USB
Package depth	260 mm
Package width	252 mm
Package height	247 mm
Package volume	16.1834 L
Package weight	2200 g
Quantity per pack	1 pc(s)
Master (outer) case width	280 mm
Master (outer) case length	510 mm
Master (outer) case volume	37556.4 cm³

Weight and Dimensions

Depth	187 mm
Width	178 mm
Height	134 mm
Weight	890 g
