Dymo LabelWriter 4XL Quick Start Guide

5
4. Loading Labels
Important!
In order for the labels to feed properly during printing, pay attention to the following when loading
labels on the spool and into the printer:
• The label spool guide must be pushed flush against the label roll, with no gap. See
Figure 6.
• The labels must be loaded with the left edge of the label inserted against the left edge of the
label feed slot. See Figure 8.
To load a label roll
1 Press the form-feed button to eject the labels that protected the printer
during shipment.
2 Open the top cover and remove any packing material inside the
label compartment.
3 Remove the label spool from inside the top cover and pull the spool
guide from the spindle.
4 Hold the spool spindle in your left hand and place the label roll on the spindle so that the labels
feed from underneath and the left edge of the label roll is firmly against the side of the spool.
See Figure 5.
Figure 5
Spool
guide
Spool
spindle

Dymo LabelWriter 4XL Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	106 mm
Mac compatibility	Yes
Compatible operating systems	Windows XP, Vista, 7 Mac OS v.10.4 +
Product color	Black, Silver
Customs code	8443321000
Country of origin	China
Dimensions (WxDxH)	178 x 187 x 134 mm
Quantity outer carton	2 pc(s)
Net weight of outer carton	4.400 kg
Gross weight of outer carton	4.850 kg
Wi-Fi	-
Standard interfaces	USB
Package depth	260 mm
Package width	252 mm
Package height	247 mm
Package volume	16.1834 L
Package weight	2200 g
Quantity per pack	1 pc(s)
Master (outer) case width	280 mm
Master (outer) case length	510 mm
Master (outer) case volume	37556.4 cm³

Weight and Dimensions

Depth	187 mm
Width	178 mm
Height	134 mm
Weight	890 g
