Dymo LabelWriter 4XL Quick Start Guide

7
5. Printing your First Label
The first time you open the application, you are asked to register the software. Registering the
software ensures that you will be informed of any software updates.
During the registration process, you will be asked to enter the serial number for your label printer.
The serial number is located on the bottom of the printer.
To print your first label
1 Double-click to start DYMO Label software.
The first time you start DYMO Label software, a list of available label types is displayed on the
left side of the window and an address label is displayed in the Edit area. (See Figure 9.)
2 Select the Shipping Extra Large label type from the Labels tab, and then select a layout.
The label is displayed in the Edit area with the layout you selected.
3 Click once in the shipping label in the Edit area and type some text.
4 Optionally, choose a font and a justification setting from the Formatting toolbar.
5 Click to print the label.

Dymo LabelWriter 4XL Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum printing width	106 mm
Mac compatibility	Yes
Compatible operating systems	Windows XP, Vista, 7 Mac OS v.10.4 +
Product color	Black, Silver
Customs code	8443321000
Country of origin	China
Dimensions (WxDxH)	178 x 187 x 134 mm
Quantity outer carton	2 pc(s)
Net weight of outer carton	4.400 kg
Gross weight of outer carton	4.850 kg
Wi-Fi	-
Standard interfaces	USB
Package depth	260 mm
Package width	252 mm
Package height	247 mm
Package volume	16.1834 L
Package weight	2200 g
Quantity per pack	1 pc(s)
Master (outer) case width	280 mm
Master (outer) case length	510 mm
Master (outer) case volume	37556.4 cm³

Weight and Dimensions

Depth	187 mm
Width	178 mm
Height	134 mm
Weight	890 g
