11
Checkthatthegarageheatersoutletgrillisnotcoveredorobstructedinanyway,and
makesurethepowertotheunitisswitchedon.
SETTING THE THERMOSTAT
1.Rotatethermostatknobclockwisetodesiredposition,POWERINDICATORwill
turnyellow.
2.Afterroomreachesdesiredcomfortleveltheheaterwillturnoff.Heaterwillcycle
onandofftomaintainroomtemperature.
SELECTION SWITCH
UsingtheSELECTIONSWITCH,youcancontroltheheatingoutput:Ifor3000W,IIfor
4000W,IIIfor5000W.
THERMAL CUT-OUT
Theheaterwillautomaticallyshutoffwhenpartsofitoverheat.Theheaterwillturn
ONagainwhentheabnormaltemperaturereturnstonormallevels.Shouldtheunit
overheatandcausethethermalcut-outtocycle,thecauseoftheoverheatingmustbe
determinedandcorrectiveactiontakenbeforefurtheroperation.
OPERATING INSTRUCTIONS
WHENTHETHERMALCUT-OUTISACTIVATED,THECAUTIONINDICATORWILLTURNRED.
INTHISCASE,IMMEDIATELYTURNTHEHEATEROFFANDINSPECTFORANYOBJECTSON
OR ADJACENT TO THE HEATER THAT MAY CAUSE HIGH TEMPERATURES. DO NOT TAMPER
WITH ANY OF THE CONTROLS. DO NOT OPERATE THE HEATER WITH THE CAUTION
INDICATOIR GLOWING RED.
CAUTION
ADJUSTING AIR FLOW DIRECTION
1.Toturntheunitwhenithasbeeninstalledwithasinglelagbolt(asshownin
gure4a),simplyturntheentireheaterasneeded.Theunitcannotbeturned
horizontallyifithasbeeninstalledwith2lagbolts.
2.Totilttheunitvertically,loosenthebracketscrews(seeFigure5).
