Dyna-Glo EG5000DGC - Operating Instructions

10
CONNECTING THE POWER
Connectors,cable,andhardwareusedto
wiretheheater
Figure 7Figura 7
Conduit
Connector
Conduit
FlexibleConduit
FlexibleNMCable
FlexibleNMCableConnector
FlexibleConduitConnector
WHITE
BLACK
GREEN
(orbarecopper)
3ft
INSTALLATION
OPERATING INSTRUCTIONS
THE HEATER MUST BE PROPERLY INSTALLED BEFORE IT IS USED.
WARNING
4000W5000W 3000W
Control Panel
Power Indicator
(Yellow)
Caution Indicator
(Red)
Thermostat Switch
(3000W / 4000W / 5000W)
