Dyna-Glo EG5000DGC - Page 9

9
CONNECTING THE POWER
3.Theexternaltemperaturecontrol(externalthermostat)shouldbein
accordancewiththerequirementofULorCSAstandard.
4.Theleadwireofexternaltemperaturecontrol(externalthermostat)cannot
belessthan14AWG.
1.Removethescrewfromthefrontoftheunittoconnectthepowertotheheater.
2.Attachthecableconnectorstotheunit(SeeFigure7)andslidethe10-gauge
wirethroughthecableconnector.
3.Connectthewiretothepowerblocklocatedinthebaseoftheheater-See
Figure7.
4.Turnonthepoweratthemainservice.
NOTE:AllwiringmustbecarriedoutbyaCertiedElectricianandmustbein
accordancetonationalandlocalelectricalcodes.Forcertainapplications,conduit
mayberequired,SeeFigure7.Checklocalelectricalcodes.Ifyourunthewiringin
conduitandwishtobeabletoturntheheaterbesuretopurchaseenoughexible
conduittoallowtheheatertobeturned.
TO PROTECT THE HEATING ELEMENT
Whenstartingtheheater,turningthetemperaturecontrolclockwiseslowlytoterminal,
theunitstartsthefanrstthenstartstheheatingelement.
Whenshuttingofftheheater,turningthetemperaturecontrolcounter-clockwisetooff,
theheatingelementrstwillturnoffthenthefanwillrunashortcoolingcycleandthen
turnoff.
INSTALLATION
THIS APPLIANCE MUST BE GROUNDED!
THE APPLIANCE MUST CONNECT TO A CURRENT PROTECTION CIRCUIT OR DEVICE AT
50AMP OR LESS BEFORE BEING CONNECTED TO POWER SUPPLY!
WARNING
HIGHTEMPERATURES–RISKOFFIRE.KEEPFLAMMABLEMATERIALS,SUCHAS
FURNITURE,PILLOWS,BEDDING,PAPERS,CLOTHES,ELECTRICALCORDSANDCURTAINS
ATLEAST3FT.(0.9M)FROMTHEFRONTANDTOPOFTHEHEATERANDKEEPTHEMAWAY
FROMTHESIDESANDREAR.TOREDUCETHERISKOFFIRE,DONOTUSEITINAREAS
WHEREGASOLINE,PAINTORFLAMMABLELIQUIDSAREUSEDORSTORED.
WARNING
TOREDUCETHERISKOFFIRE,DONOTSTOREORUSEGASOLINEOROTHER
FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THE HEATER.
WARNING
