MULTIPLE VERTICAL ANGLES
3.Adjustlouverstothedesiredposition(seeFigure6).
NOTE: Thelouversaredesignedsotheycannot
becompletelyclosed.Donotattempttobypassthis
feature;damagetotheunitcanresult.
CEILING
90 degrees
90 degrees
seerged 54seerged 5.76
45 degrees
INSTALLATION
NOTE: Fortheheatertobetiltedvertically,itmustbemountedinbottomkeyhole
slotsofmountingbracketstomaintainadequateclearanceandpreventpossible
overheating.
Figure 6
TOPREVENTPOSSIBLEELECTRICSHOCK,DISCONNECTPOWERTOTHEHEATERATTHE
MAIN SERVICE BOX BEFORE ATTEMPTING TO ADJUST THE HEAT OUTPUT OF THIS UNIT.
WARNING
