ES52 Specifications
Operating VDC limits: 3.3VDC min - 30VDC max
Provided minimum 8VDC Present at Starting.
Standby current draw: 12.2mA at 12VDC (12.4mA at 24VDC)
Operating current draw: 140mA at 12VDC (80mA at 24VDC)
Reverse polarity protected: Internal protection will prevent damage to unit under
a reverse polarity condition. Re-connect power leads
properly, and normal operation will resume.
J1113-11 Transients Pulse 1A (Supply Disconnect), Pulse 2A (Sudden
Disconnect), Pulse 4 (Starter Motor Engagement),
Pulse 5 (Load Dump). Details of the test parameters
are available, please consult with factory.
Speed sensing input accepts: Generator AC output directly
Fly Wheel Alternator
Engine Alternator
Magnetic Pickup
Speed sensing maximum rating: Withstands Line Voltage up to 300VAC
Operating temperature range: -40
O
C to +70
O
C
Operating humidity range: 0 to 95% non-condensing
Fuel & Crank contact output: 10Amps maximum each continuous sourcing
(+Bat) output
Annunciation outputs: Sourcing (+Bat) outputs (300mA maximum per
output)
Lamp Test terminal: Close to +Battery to test LED’s
Actual unit weight: 0.67 lb (0.30kg)
Shipping weight: 1 lb (0.45kg)
Unit dimensions: 3.302” x 3.342” x 1.8”
Shipping dimensions: 4” (10.16cm) x 4” (10.16cm) x 3” (7.62cm)
