CHAPTER 2 - DEVICE DESCRIPTION
3

The LEDs indicate the Mesh Wi-Fi Router’s power and connection.
LED Name
Color status
Description
WPS
(Only functional on the
Main Router when pairing)
Green
Blinking
Press WPS button, LED start to blink green, until WPS pairing success
or fail or 2 minute timeout.
Green
Solid on
WPS paring success, change to solid green for 10 seconds, then
change to off.
Red
Solid on
WPS pairing failure or timeout, LED become solid Red for 10 seconds,
then change to off.
Mesh
Orange
Blinking
Waiting to be paired (default mode).
Green
Blinking
Paring is going on.
Green
Solid
Paired and signal quality is good.
Orange
Solid
Paired but signal quality is not good.
Red
Solid
Paring failed, will show RED for 5 seconds, and go back to previous
mode. If this device is in default mode, will go back to blinking orange.
OFF
Not paired and not in pairing mode.
Internet
Green
Device is Wifi Router and is connected to Internet.
Internet
Orange
Device is Wifi Router but not connected to Internet.
Internet
OFF
Device is Wifi Point or is in factory default mode.
System
(Power on/Reboot)
Green
Blinking
Power on (Booting). LED will blink blue for a while and become solid
blue when boot process is done successfully.
Red
Solid
Device failure.
Green
Solid on
Power on Success.
System
(Firmware Upgrade)
Green
Blinking
Firmware upgrade process, LED will blink green till upgrade is done,
then LED off and reboot.
System
(Reset to Default)
Green
Blinking
Press reset for 7+ seconds till LED start blinking, LED will blink green
for 5 seconds to start reset process. Then LED off and reboot.
