8 CC102/C/122/C/132/142/C M102EN4
1234567
19 16 15 14 13 12 11 18 17
8
9
10
22
21
20
23
MAINTENANCE SCHEDULE
Fig. 1 Service and maintenance points
1. Fuel tank
2. Refueling
3. Radiator
4. Air cleaner
5. Battery
6. Diesel engine
7. Water tank
8. Sprinkler system/Drum
9. Scrapers/Drum
10. Rubber elements and fastening screws
11. Filling hydraulic fluid
12. Hydraulic reservoir
13. Hydraulic filter
14. Hydraulic fluid sight glass
15. Steering joint
16. Steering cylinder mounts
17. Filler plugs/Drum
18. Oil level in drum
19. Tires/Tire pressure
20. Sprinkler system/Wheels
21. Scrapers/Wheel
22. Emulsion tank
23. Reserve/parking brake control
