17CC102/C/122/C/132/142/C M102EN4
Do not allow anyone near the steering joint
when the engine is running. Danger of
being crushed when steering is operated.
Push the reserve/parking brake knob befo-
re lubricating.
Turn the steering wheel fully to the left to gain access
to all four grease nipples (1) from the right side of the
machine.
Wipe the grease nipples (1). Grease each nipple with
five strokes of the hand-operated grease gun. Make
sure that grease penetrates the bearings. If grease
does not penetrate the bearings, you may need to
relieve the articulation joint with a jack while repeating
the greasing process.
Steering cylinder and steering
joint – Lubrication
1
Fig. 20 Steering joint
1. Grease nipples
1
Tires – Tire pressure
Fig. 21 Tires (Combo)
1. Air valve
Check the tire pressure with a pressure gauge.
Make sure that the tires have equal pressure.
Recommended pressure: See Technical
Specifications.
EVERY 50 HOURS OF OPERATION (Weekly)
