Dynascan 10M - Installation

English - 5 -
3.- SUPPLIED ARTICLES:
Mobile transceiver
DYNASCAN 10M
Microphone Mounting bracket Microphone
Hanger
Non-slip mat Power cable Screws for bracket
Pads for bracket
Adjusting screws Spare fuses
(15 A, 250 V)
Self-tapping screws Pads
4.- INSTALLATION:
Choose the most appropriate setting from a simple and practical point of view. Your transceiver
should not interfere with the passengers, or vehicle driver or crash the
driver's knee or leg when rush brake.
1.- Using the self-tapping screws and pads(2 sets) to fix the bracket.
2.- Put the non-slip mat on the 2 ends of the bracket and put in the
transceiver. Then, insert the adjusting screws and check careful each
screws, make sure the screws and machine will not lose when the car
shaking.
3.- Choose suitable angle by the 3 screw holes in the two ends of
bracket.
