Dynascan 10M - User Interface Components

English - 10 -
MICROPHONE:
LCD DISPLAY:
No. Icon Description
1 RX signal strength indicator.
2 TX signal strength indicator.
3 SWR strength indicator.
4 Model name indicator.
5 Keypad lock function activated.
6
FUNC
Appears when press [MENU] key.
