Dynascan 10M - Transceiver Operation; Operation Controls

English - 11 -
7
EMG
Appears when using emergency channel.
8
FIN
RT
Appears when adjust SSB clarifier frequency.
9
AQ
Appears when use “AQ” function.
10
SC
Appears when scan function is ON.
11 Display the modulation type.
12
CTC
Appears when the “CTCSS” signaling is enabled.
13
DCS
Appears when the “DCS” signaling is enabled.
14
HIC
Appears when “Hi-cut” function is ON.
15
BP
Appears when keypad “beep” is ON.
16
RB
Appears when “Roger beep” function is ON.
17
REP
Appears when “Offset” function is ON.
18
DW
Appears when dual-watch function is ON.
19
NB
Appears when noise blanker function is ON.
20
10k
Appears when add “+10 kHz” function is ON.
21
ECHO
Appears when “echo” function is ON.
22 Working band indicator.
23
●
Appears when scan function is ON.
24 Display of frequency or channel.
6.- TRANSCEIVER OPERATION:
TURN ON/OFF THE TRANSCEIVER:
1.- Turn the [VOL] knob clockwise to switch ON the transceiver, the transceiver emit a “beep”.
When the LCD displays frequency or channel, the transceiver is ON mode.
2.- Turn the [VOL] knob anti-clockwise to switch OFF the transceiver, the transceiver is OFF when
hear “click” from the knob.
VOLUME CONTROL:
When the transceiver is turned ON, turn the [VOL] knob clockwise to increase the volume, turn the
[VOL] anti-clockwise to reduce the volume. The LCD displays “VOL: XX” (“XX” stands for the
volume level, total 1-36 levels).
Note:
- Adjust the volume during communication to get suitable level.
RF POWER CONTROL:
When the transceiver is in transmitting mode, turn the [PWR] outer shaft knob to adjust power.
Turn it clockwise to increase power, anti-clockwise to reduce it.
RF GAIN CONTROL:
When the transceiver is in receiving mode, turn the [RFG] inner shaft knob to adjust RF gain. Turn
it clockwise to increase gain, anti-clockwise to reduce.
