English - 16 -
Frequency control: PLL synthesizer.
Frequency step: 100 Hz, 1 kHz, 10 kHz, 100 kHz, 1 MHz.
Frequency tolerance: 0.005 %.
Frequency stability: 0.001 %.
Temperature range: -20º C to +55 ºC.
Microphone: With [PTT], [UP] / [DN] keys and coiled cord.
Operating voltage: 13.8 VDC.
Antenna impedance: 50
Ω.
Antenna connector: SO239, UHF.
Dimensions (mm): 250 (W) x 280 (L) x 60 (H).
Weight: 1.5 Kg.
Duty cycle: 3-3-54 minutes (Rx-Tx-Standby).
9.2.- TRANSMITTER:
RF power: 12 W (AM), 30 W (FM), 30 W (PEP in SSB).
Current: 8 A (with modulation).
Intermodulation distortion: SSB: 3rd order >-25dB; 5th order >-35 dB.
SSB carrier suppression: 55 dB.
Unwanted sideband: 50 dB.
Spurious emission: <50 dB.
9.3.- RECEIVER:
Sensitivity: 0.25 µV SSB for 10 dB (S+N)/N.
1 µV AM for 10 dB (S+N)/N.
1 µV FM for 20 dB (S+N)/N.
Adjacent channel selectivity: AM/FM: 60 dB, SSB: 70 dB.
Image rejection: >65 dB.
IF frequency: AM/FM/SSB: 10.685 MHz 1st IF; AM/FM: 2nd IF: 455 kHz.
RF gain control: 45 dB, adjustable for optimum signal reception.
Automatic gain control: <10 dB in audio output, for inputs from 10 µV to 100 µV.
Squelch: Adjustable for threshold less than 1 µV.
Automatic squelch control 1 µV (only AM and FM).
Audio output power: 3 W @ 8 Ω.
Frequency response: AM/FM: 300 Hz to 3000 Hz; SSB: 450 Hz to 2500 Hz.
Built-in speaker: 8 Ω, round.
External speaker (Not supplied): 8 Ω. Disable internal speaker when connected.
Spurious radiation: <50 dB.
