DS752LT5 User Manual 21
Navigating the On Screen Display (OSD) Menu
Press the MENU button on the built-in keypad or remote control to show the OSD. Use the
navigation arrows to select and adjust the menu items.
*The change of each setting can only enable when you press “LEFT” (refer to p.19) to back to the last
menu layer.
1. Input Source
ITEM 1 ITEM 2 DEFAULT DESCRIPTION
Main HDMI 1 Set the Main input to display.
Failover 1 HDMI 2 Set the Failover 1 input to display.
Failover 2 DP Set the Failover 2 input to display.
Failover 3 DSM365 Set the Failover 3 input to display.
Input Source
Failover 4 SDM Set the Failover 4 input to display.
2. Picture
ITEM 1 ITEM 2 DEFAULT DESCRIPTION
Color
Temperature
USER 2
Select the color temperature. (User2, User1,
D93, D65 and D55).
Red
Adjust the red light level. Range 0 – 100.
Note: The feature is only supported on
User2 mode.
Green
Adjust the green light level. Range 0 – 100.
To Next Page
