Rev. 01/11 -3.1- TFXL-X
PART 3 - PROGRAMMING
The TFXL flow meter is available with a software utility called
ULTRALINK™. The ULTRALINK™ utility is used for configuration,
calibration and communication with the TFXL flow meter.
ULTRALINK™ has been designed to provide a TFX user a powerful
and convenient way to configure and calibrate all TFX flow meters.
ULTRALINK™ can be used in conjunction with a PC communications
cable—Dynasonics P.N. D010-0204-001.
System Requirements
Computer type - PC, Windows 2000, Windows XP, Windows Vista
®
, or
Windows
®
7 operating system, a communications port, hard disk.
Installation
1. ULTRALINK™ can be found on the Dynasonics website for no
charge or a CD can be purchased by contacting Dynasonics
sales.
2. Backup/Copy all files from the website link to a folder on the
computer hard disk.
3. From the "Start" command, RUN UlSetup.exe from the hard disk
folder.
4. UlSetup will automatically extract and install on the hard disk
and place a short-cut icon on the desktop.
5. Most PCs will require a restart after a successful installation.
Initialization
1. Connect the PC to the TFX flow meter using the PC
communications cable, Dynasonics P.N. D010-0204-001. See
Figure 3.1 on page 3.2.
2. Double-click on the ULTRALINK™ icon. The first screen is the
“RUN-mode” screen, see Figure 3.2 on page 3.2, which
contains real-time information regarding flow rate, totalizer
accumulation, system signal strength, diagnostic data and the
flow meter’s serial number. The indicator in the lower right-hand
corner will indicate communications status. If a red ERROR is
indicated, click on the Communications button on the top bar.
Important
Notice!
