CLEANING PROCEDURE

1) Remove the four (4) brass nuts at the end

head and hinge the head down to expose the

tubes and scroll. Inspect the scroll for cracks

and other damage, and replace the scroll if

necessary.

2) Clean the fire tubes with a shop vacuum

and/or tube brush. If there is any carbon

inside the combustion tube, clean it out.

3) Inspect the end head refractory insert and

replace if necessary.

4) Clean the inspection sight glass and replace if

necessary.

5) Replace the end head rope gasket.

6) Remove the inspection plate at the front head

(burner end) and clean the inside thoroughly

with a vacuum.

7) Remove the flue cap and clean inside the

belly pan. Replace the flue cap once finished.

8) Inspect the exhaust pipe and tape, and clean

or repair if necessary.

9) Clean or replace the burner nozzle per the

burner manual, making sure to use the proper

size and angle.

10) If using No. 2 fuel oil, replace the oil filter

element.

11) If there is any indication that any other

gaskets are leaking, replace those gaskets

immediately.

12) Reinstall the cleanout cover, scroll, end head

and stack connections. Make sure that all

vent connections are taped and secured with

screws.

⚠ WARNING

Do not omit the scroll. The scroll is important to

assure the efficient operation of the boiler.

13) Fire up the boiler and double check for any

leaks in gaskets or stack joints. Make sure the

, air control setting and smoke test are to

the recommended levels. Refer to the Initial

Burner Setup & Start-Up section of this

manual.
