BURNER CONFIGURATIONS
APPLIANCE
VENTING
ARRANGEMENT
BOILER
MODEL
BURNER
MODEL
CONTROL
PRE/POST PURGE
NOZZLE SIZE
AIR
SETTING
TURBULATOR
OR HEAD
SETTING
PUMP OR
MANIFOLD
PRESSURE
FLANGE
INSERTION
DEPTH
Chimney Vented
FP18 Oil
EZ-1 PRO
6020002 10/10
0.55x45°B
0.60
0.50
150 psig
3” to flange
FP18 Oil
EZ-1 PRO
0.65x45°B
0.65
0.60/0.65
FP18 Oil
EZ-1 PRO
0.75x45°B
0.75
0.75
Direct Vented
FP18 DV
EZ-1 PRO DV
6020002 15/120
0.55x45°B
0.45
0.60/0.65
150 psig
3” to flange
FP18 DV
EZ-1 PRO DV
0.65x45°B
0.55
0.75
FP18 DV
EZ-1 PRO DV
0.75x45°B
0.65
0.85/1.00
Chimney Vented
FP24 Oil
EZ-1 PRO
6020002 10/10
0.75x45°B
0.75
0.75
150 psig
3” to flange
FP24 Oil
EZ-1 PRO
0.85x45°B
0.85
0.85/1.00
FP24 Oil
EZ-1 PRO
1.10x45°B
1.10
1.10/1.25
Direct Vented
FP24 DV
EZ-1 PRO DV
6020002 15/120
0.75x45°B
0.65
0.85/1.00
150 psig
3” to flange
FP24 DV
EZ-1 PRO DV
0.85x45°B
0.85
1.10/1.25
FP24 DV
EZ-1 PRO DV
1.10x45°B
1.15
1.35/1.50
Chimney Vented
FP36 Oil
EZ-1 PRO
6020002 10/10
1.00x45°B
1.15
0.85/1.00
150 psig
3” to flange
FP36 Oil
EZ-1 PRO
1.10x45°B
1.15
1.10/1.25
FP36 Oil
EZ-1 PRO
1.25x45°B
1.20
1.35/1.50
Direct Vented
FP36 DV
EZ-1 PRO DV
6020002 15/120
1.00x45°B
1.20
1.10/1.25
150 psig
3” to flange
FP36 DV
EZ-1 PRO DV
1.10x45°B
1.20
1.35/1.50
FP36 DV
EZ-1 PRO DV
1.25x45°B
1.60
1.65
Chimney Vented
FP48 Oil
EZ-66
6020002 30/30
1.50x30°B
80%
6-8 set at 7
150 psig
3” to flange
FP48 Oil
EZ-66
1.65x30°B
100%
6-8 set at 7
NOTES:
A) All “B” burner nozzles listed above for EZ-1 oil burners are Hago or Delavan.
B) The air tube for the FP18, FP24 & FP36 are 7” in length.
C) The air tube for the FP48 are 11” in length.
