NOTES:
A) 3-1/2” water column manifold pressure.
B) 4” long orifice nipple is used. The orifice faces toward the gas valve.
APPLIANCE
VENTING
ARRANGEMENT
BOILER
MODEL
BURNER
MODEL
CONTROL
PRE/POST PURGE
FIRING RATE
NATURAL
GAS
ORIFICE
NATURAL
GAS AIR
SETTING
PROPANE
ORIFICE
PROPANE
AIR SETTING
Chimney Vented
FP18 Gas
EZ-GAS
6020002FR
30/6/30
91 MBH
13/64”
15%
9/64”
12%
FP18 Gas
EZ-GAS
105 MBH
.213” (#3)
22%
9/64”
23%
FP18 Gas
EZ-GAS
119 MBH
15/64”
32%
11/64”
33%
Direct Vented
FP18 DV
EZ-GAS DV
6020002FR
30/6/30
91 MBH DV
13/64”
5%
9/64”
6%
FP18 DV
EZ-GAS DV
105 MBH DV
.213” (#3)
8%
.159” (#21)
8%
FP18 DV
EZ-GAS DV
119 MBH DV
15/64”
11%
11/64”
12%
Chimney Vented
FP24 Gas
EZ-GAS
6020002FR
30/6/30
119 MBH
15/64”
41%
11/64”
42%
FP24 Gas
EZ-GAS
140 MBH
17/64”
60%
13/64”
60%
FP24 Gas
EZ-GAS
175 MBH
5/16”
90%
.238” (B)
90%
Direct Vented
FP24 DV
EZ-GAS DV
6020002FR
30/6/30
119 MBH DV
15/64”
8%
11/64”
11%
FP24 DV
EZ-GAS DV
140 MBH DV
17/64”
18%
13/64”
18%
FP24 DV
EZ-GAS DV
175 MBH DV
5/16”
37%
.238” (B)
28%
Direct Vented
FP36 Gas
EZ-GAS
6020002FR
30/6/30
175 MBH
5/16”
50%
.238” (B)
40%
FP36 Gas
EZ-GAS
189 MBH
.332” (Q)
60%
.257” (F)
53%
FP36 Gas
EZ-GAS
210 MBH
3/8”
83%
.277” (J)
67%
Direct Vented
FP36 DV
EZ-GAS DV
6020002FR
30/6/30
175 MBH DV
5/16”
37%
.238” (B)
32%
FP36 DV
EZ-GAS DV
189 MBH DV
.332” (Q)
43%
.257” (F)
42%
FP36 DV
EZ-GAS DV
210 MBH DV
3/8”
75%
.277” (J)
85%
