Protection circuit
To prevent thermal overload, the mute circuit will be activated at 65°C (149° F) and will be
automatically deactivated when the temperature drops to 50°C (122° F). Under normal
conditions this should rarely occur.
Power switch
Switches the power on and off. When the subwoofer is on, the power switch lights up.
AC inlet
This is a grounding-type plug.
If the sound system has an AC convenient outlet, connect the power supply cord from the
subwoofer to this device. Otherwise connect it to an AC wall outlet.
Voltage switch
The voltage switch is positioned according to area voltage requirements. It has been pre-set
prior to shipping from the factory.
CAUTION
Do not try to alter the voltage setting, as doing so will result in a blown fuse. A wrong setting
may result in damaged electronics.
Fuse-drawer
The main fuse for the subwoofer is located in the Fuse-drawer.
CAUTION
For continued protection against risk of fire, replace only with same type of fuse.
Fuse rating: 115 V: 1.6 A / 125 V Slow-blow
230 V: 0.8 A / 250 V Slow-blow
