Dynaudio Sub 6 Owner's Manual

3332
Conguration and Use
Sub6 Troubleshooting Matrix
Problem Cause Solution
The subwoofer switches itself off
although music is playing.
There is hardly any low-frequency signal
available. This can happen if the music
or movie itself does not contain very low
frequencies (e.g. long dialogues).
•
The subwoofer will switch on
automatically as soon as low
frequency signals are detected.
The subwoofer will not switch on. • AC mains cable has become
disconnected.
• Mains switch on the rear is switched
to OFF.
Make sure to switch the system
off rst before making any
changes!
•
Reconnect mains cable.
•
Switch mains back on.
•
Check if all signal cables are
connected properly.
The subwoofer will not switch on
automatically.
• No signal is present on either of the
subwoofer’s inputs (LED lights red).
Make sure to switch the system
off rst before making any
changes!
•
Check if all signal cables are
connected properly.
•
Check if the subwoofer output on the
source is active.
Subwoofer is switched on not making
any sound.
• No signal is present on either of the
subwoofer inputs.
• In the processor or receiver’s bass-
management set-up, subwoofer has
been disabled.
• Subwoofer volume level has been
turned down on the processor/
receiver.
• Volume is turned down on the
subwoofer controls.
Make sure to switch the system
off rst before making any
changes!
•
Check if all signal cables are
connected properly.
•
Check settings in Bass Management
menu of the connected amplier or
receiver.
•
Carefully and gradually increase
the subwoofer volume level on the
amplier or receiver.
•
Carefully and gradually increase
the subwoofer volume level on the
subwoofer GAIN control.
Sub6 Specication
Data Sub6
System Twin opposed driver, closed box, active DSP subwoofer
Analog inputs 2x balanced XLR, 2x unbalanced RCA phono
Max. input voltage 1.01Vrms @ +6dB Sensitivity, 2.0Vrms @ 0dB Sensitivity
4Vrms @ -6dB Sensitivity, 10.1Vrms @ -14dB (LFE) Sensitivity
Analog outputs 2x balanced XLR, 2x unbalanced RCA phono
XLR output impedance Differential: 200Ω, Single-ended: 100Ω
Phono output impedance 100Ω
XLR Pin-out Pin 1: ground, Pin 2: signal +, Pin 3: Signal –
Frequency response 16Hz–230Hz ±3dB
Auto ON/OFF Ye s
Box Principle Sealed
Low Pass Filter Adjustable/preset
Phase Adjustment 0/180 degrees
Woofer 2x24cm MSP+ Hybrid Drive
Amplier power 500W
AC power input 100-120V/220-240V 50/60Hz
Standby power consumption <0.5W
Maximum power consumption 490W
Weight 21.5kg/45.2lb
Dimensions (WxHxD) 447x300x268mm/17.6x11.8x10.6in
Dimensions with feet/grill (WxHxD) 470x333x268mm/18.5x13.1x10.6in

Dynaudio Sub 6 Specifications

General

Subwoofer type	Active subwoofer
Number of subwoofers	2
Subwoofer peak power	500 W
Subwoofer driver diameter	240 mm
Subwoofer frequency range	16 - 230 Hz
On/off switch	Yes
Product color	Black
Speaker enclosure	Closed
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W

Weight and Dimensions

Subwoofer depth	268 mm
Subwoofer width	447 mm
Subwoofer height	300 mm
Subwoofer weight	21500 g
