Dynojet Power commander V - Ignition Coil and Front O2 Sensor Wiring; PCV to Ignition Coil Connection; O2 Optimizer to Front Sensor

25-010 www.powercommander.com 11-12 CanAm Spyder RT PCV - 7
FIG.O
23 Route the O2 Optimizer harness as shown in Figure O.
The connectors labeled front route to the left side of the air box.
O2 harness
O2 harness
22 Plug the PCV connectors in-line of the stock ignition coil and wiring harness
(Fig. N).
This connection is located on the left side near the oil tank. The connector is
on the front of the coil, squeeze the tab and pull forward to release.
FIG.N
Coil
FIG.P
24 Unplug the stock wiring harness from the front O2 sensor (Fig. P).
This connection is located on the left hand frame rail by the front cylinder
25 Plug the 4 pin connector from the O2 Optimizer labeled FRONT in-line of the
stock O2 sensor and wiring harness.
