Dyson V8 User Manual

1
2
5 hrs
click
Battery LEDs
Charging LEDs
During use, high charge.
Charging, low charge.
Charging, medium charge.
Charging, nearly full.
Fully charged.
Battery fault.
Charger fault.
During use, medium charge.
During use, low charge.
Empty.
4.5 hrs4.5 hrs
1
2
5 hrs
click
1
2
5 hrs
click
1
2
5 hrs
click
1
2
5 hrs
click
1
2
5 hrs
click
Charging your machine
Fully charge your machine before your first use. Connect to charger either
directly or in the dock.
A full charge will take approximately 4.5 hours. While your battery
is charging, the LEDs will flash with the current level of charge.
These lights will turn off once your machine is fully charged.
clik
1
click
One light flashing
alternately red and blue.
Two flashing blue lights on
the side of the battery.
No lights illuminated on
the side of the battery.
Three flashing blue lights
on the side of the battery.
One flashing blue light on
the side of the battery.
One flashing red LED.
All LEDs lit with
a solid blue light.
Two LEDs lit with
a solid blue light.
One LED lit with
a solid blue light.
One blue LED flashing.
The LED lights
are located on
the side of the
battery unit.
The charger connected
from the power supply
using the wall dock.
Insert the charging cable into the charging point at the back of
the vacuum, at the bottom of the handle. Plug the cable into
a wall socket to begin charging.

Dyson V8 Specifications

General

Package depth	154 mm
Package width	271 mm
Package height	739 mm
Package weight	3900 g
Rotational speed	110000 RPM
Commodity Classification Automated Tracking System (CCATS)	8508110003
Cleaning type	Dry
Power control	Auto
Country of origin	Malaysia
Filtration system	Yes
Number of settings	2
Vacuum air filtering	-
Dirt separating method	Cyclonic/filtering
Power source	Battery
Charging time	5 h
Battery voltage	- V
Number of battery cells	6
Product color	Nickel
Dust container type	Bagless
Vacuum brushes included	Motorized brush

Weight and Dimensions

Depth	250 mm
Width	221 mm
Height	1256 mm
Weight	2560 g
