1. Turn on the transmitter and receiver of your
Cap 232 BP. Check the movement of the rudder using
the transmitter. When the stick is moved right, the
rudder should also move right. Reverse the direction of
the servo at the transmitter if necessary.
2. Check the movement of the elevator with the radio
system. Moving the elevator stick down will make the
airplane elevator move up.
3. Use a ruler to adjust the throw of the elevator,
ailerons and rudder. Adjust the position of the
pushrod at the control horn to achieve the
following measurements when moving the sticks
to their endpoints.
Ailerons
Low Rate: 1
1
/4" (32mm) with 20% Expo (Up/Down)
High Rate: 1
3
/4" (45mm) with 43% Expo (Up/Down)
Elevator
Low Rate: 2" (50mm) with 20% Expo (Up/Down)
High Rate: 3" (75mm) with 49% Expo (Up/Down)
Rudder
3" (75mm) (Left/Right)
Control Throws
38
