E-FLITE Opterra - Model Assembly

EN
Model Assembly
1. Slide the wing tube into the fuselage.
2. Slide the wings onto the wing tube.
3. Press the wing panels together onto the fuselage until the wings click into
place.
4. Insert the vertical fi ns into the pockets on top of the fuselage until the fi ns
click into place. The vertical fi ns should angle outward.
Wing Installation
6
Opterra
®
1.2M
